Neonatal Line AMPLA 2085LED

Intensive Care Unit Ampla 2085 LED infant warmer is a medical electrical device equipped with a heating element which provides radiant heat. Its function is to provide thermal support to the patient by the system of irradiant heat. This emitted energy is absorbed by the newborn skin, increasing the blood flow on the skin and then transfers the heat to the rest of the body through convection between blood and tissues surface and by conduction amount tissues.

Main Features

• Radiant warmer with quartz heater for optimum dosage of low-infrared to the skin;
• Warming functions: Pre-heating, manual and skin (servo-controlled);
• Energy-efficient heater: 650 W;
• LEDP Articulated Irradiation reflector with built-in LED examination lamp 400 lumens, and optional dimmable 1000 lumens;
• Intelligent audiovisual alarms with auto-test;
• 8.4” panel with LED display functions operated through a rotary adjust button;
• APGAR clock;
• Mounted on sturdy base on four 5” castors with brakes and rear handles for transportation, optional 320mm Height adjustment;
• Ø 25 mm holes for draining system and O₂ wire guide;
• Ambient temperature displayed on the screen;
• Servo-controlled skin temperature probe and peripheral auxiliary probe;
• 03 drawers of 06 with different fitting according to application, 02 of which include collapsible shelves and can be used by X-Ray tray;
• Choice of heads for adaptation according to application with suction unit, T-piece resuscitator, air-oxygen blender, mechanical ventilator and suitable jar for CPAP;
• 2 advanced gas infant SUPRA phototherapy, for top or from underneath through gel mattresses;
• In-built weighing scale (optional);
• Lower tray with 02 choices of containers and shelves;
• External shelves and pole for infusion pump (optional);
• Auxiliary sockets for peripherals (optional);
• Electronic X-Ray cassette drawer (optional);
• Goose Neck – flexible ventilator circuit support (optional).

Technical Data

• Rechargeable Battery (Panel): 9 V, 170 mAh;
• Max % Frequency: 60 Hz;
• Power: 1000 VA;
• Supply Voltage: 127 or 220 or 240 V ±10%;
• Classification: Class I Equipment (Power cord: 3-wire cable); 3BF Type Applied Part;
• Protection against Electrical Penetration: Equipment: IP20, Protection against Water Penetration: Fluid: IP22;
• Operating Mode: Continuous Operation;
• Height (Fixed Support): Approx. 1830 mm;
• Height (Adjustable Height Support): 790–1200 mm ±15%;
• Height (Fixed Support – Radiant Warmer Level): 1000 mm ±15%;
• Height (With Adjustable Height) – Mattress Level: 110–810 mm ±15%;
• Weight (Standard Set): ≈ 86 kg;
• Weight (With All Accessories): ≈ 118 kg;
• Maximum Weight of Wrapped Equipment: 120 kg.
